FEP Insulated Thermocouples

view larger image
These flexible FEP insulated sensors are ideally suited to applications which require resistance to attack from virtually all known chemicals, oils and fluids. Available in Type K or T thermocouple combinations, 0.157” in diameter, in a variety of lengths which can be cut down to an exact length by the user if necessary. The sensing junction is encapsulated in the tip and the whole sensor is rated to 392ºF. Adjustable PTFE compression fittings for an exact insertion length in your process are also available in either 1/4 inch or 1/2” NPT.
  • Thermocouple types K and T available
  • Sheath: FEP insulated 0.157” OD in a variety of lengths
  • Operating range: -100ºF to +392ºF (-75ºC to +200ºC)
  • Insulated junction
The following types are available:
Type K FEP Thermocouple
Order Code Description 1 - 4 5 - 9 10 - 19 Buy
207-170 0.157" O.D. x 36" long $61.00 $55.00 $49.90 Add
207-176 0.157" O.D. x 72" long $79.00 $72.00 $66.00 Add
207-182 0.157" O.D. x 180" long $148.00 $135.00 $123.00 Add
276-200 1/4" NPT PTFE Fitting to suit 0.157" sensor $38.50 $35.10 $32.10 Add
276-210 1/2" NPT PTFE Fitting to suit 0.157" sensor $46.70 $42.60 $39.10 Add
Type T FEP Thermocouple
Order Code Description 1 - 4 5 - 9 10 - 19 Buy
207-250 0.157" O.D. x 36" long $61.00 $55.00 $49.90 Add
207-256 0.157" O.D. x 72" long $79.00 $72.00 $66.00 Add
207-262 0.157" O.D. x 180" long $148.00 $135.00 $123.00 Add
276-200 1/4" NPT PTFE Fitting to suit 0.157" sensor $38.50 $35.10 $32.10 Add
276-210 1/2" NPT PTFE Fitting to suit 0.157" sensor $46.70 $42.60 $39.10 Add
