Miniature 0.010” and 0.020” dia Mineral Insulated Thermocouple with Miniature Flat Pin Plug
These miniature semi rigid thermocouples are ideal for many demanding precision temperature measurement applications due to the response, size, displacement and robustness of the assembly. Applications are varied from laboratory work to situations where the temperature changes are rapid and require a sensor to cope with this sudden change. They have insulated junctions to prevent earth loops and can be formed to shape to suit particular applications without impairing performance. A miniature flat pin plug is incorporated and is compatible with the miniature thermocouple jacks available in this catalog. A variety of extension cables and adjustable compression fittings can also be found in this catalog to complement this product.
- Rapid response, minimum size and least displacement
- Thermocouple types K, T or J available
- Sheath diameter: 0.010” or 0.020”
- Variety of lengths available
- Sheath Material: 316 Stainless Steel
- Operating range: -148ºF to 1472ºF (-100ºC to 800ºC)
- Insulated Junction
- Terminated in a miniature plug rated to 275ºF
The following types are available:
