Leaf Thermocouple

view larger image
This sensor has a fast response thermocouple mounted on a stainless steel shim which allows it to be welded, soldered or placed under banding on a variety of applications including nozzle or band heaters. It is supplied with 72” leads supplied with 72” leads and available with a miniature plug termination
  • Thermocouple types K, T, J or N, grounded junction
  • Stainless steel leaf dimensions: 0.5” x 1”
  • Leads: 72” fiberglass or alternatively stainless steel braided fiberglass
  • Operating range -22ºF to +660ºF (-30ºC to +350ºC)
The following types are available:
Leaf Thermocouple With Leads
Order Code Description 1 - 9 10 - 24 25 - 49 Buy
201-340 Type K - Fiberglass Leads $27.00 $24.70 $22.70 Add
201-343 Type K - Stainless Steel/Fiberglass Leads $29.90 $27.30 $25.00 Add
201-346 Type T - Fiberglass Leads $27.00 $24.70 $22.70 Add
201-349 Type T - Stainless Steel/Fiberglass Leads $29.90 $27.30 $25.00 Add
201-352 Type J - Fiberglass Leads $27.00 $24.70 $22.70 Add
201-355 Type J - Stainless Steel/Fiberglass Leads $29.90 $27.30 $25.00 Add
201-358 Type N - Fiberglass Leads $27.00 $24.70 $22.70 Add
201-361 Type N - Stainless Steel/Fiberglass Leads $29.90 $27.30 $25.00 Add
Leaf Thermocouple With Leads and Miniature Plug
Order Code Description 1 - 9 10 - 24 25 - 49 Buy
201-370 Type K - Fiberglass Leads $36.20 $33.00 $30.30 Add
201-373 Type K - Stainless Steel/Fiberglass Leads $38.80 $35.50 $32.50 Add
201-376 Type T - Fiberglass Leads $36.20 $33.00 $30.30 Add
201-379 Type T - Stainless Steel/Fiberglass Leads $38.80 $35.50 $32.50 Add
201-382 Type J - Fiberglass Leads $36.20 $33.00 $30.30 Add
201-385 Type J - Stainless Steel/Fiberglass Leads $38.80 $35.50 $32.50 Add
201-388 Type N - Fiberglass Leads $36.20 $33.00 $30.30 Add
201-391 Type N - Stainless Steel/Fiberglass Leads $38.80 $35.50 $32.50 Add
