USB datalogger - Voltage and 4-20mA Loop
These data loggers measure and store up to 32,000 readings over a 0 to 30Vd.c. or 4 to 20mA range. The user can easily set up the logging rate and start time, and download the stored data by plugging the data logger into a PC’s USB port and running the purpose designed software under Windows 7, Vista and XP. The data can then be graphed, printed and exported to other applications. The data logger is supplied complete with a long-life lithium battery. Correct functioning of the unit is indicated by a flashing red and green LED. The data logger features a pair of screw terminals in the cap and is supplied complete with a set of measurement leads terminating in crocodile clips.
- 0 to 30V d.c. voltage measurement range (357-770)
- 4-20mA current loop measurement range (357-780)
- USB Interface for Set-up and Data Download
- Connection via two screw terminals in the cap
- User-programmable alarm thresholds
- Status indication via red and green LEDs
- Supplied with Internal Lithium Battery and Windows Control Software
- Datalogger Set-ups: Logger Name, Logging Rate (1s, 10s, 1m, 5m, 30m, 1hr, 6hr, 12hr), High and Low Alarms, Start Date and Start Time
The following types are available:
